مانیتور صنعتی پاناسونیک مدل TH-49SF2U

Specification	Description
Brightness	450 cd/m2
Contrast Ratio	1100:1
Aspect Ratio	16:9
Response Time	12 ms (G to G)
Effective Display Area (W x H)	1073 x 604 mm (42.2" x 23.7")
Number of Pixels (H x V)	1920 x 1080 pixels
Panel Type	LCD IPS Panel/E-LED
Viewing Angle (Horizontal/Vertical)	178°/178° (CR≧10)
Dynamic Contrast	50000:1
Weight	14.7 kg(32.4 lbs.)
Power consumption	110W
Power Requirements	110-127/220-240 V AC,50/60 Hz
Operating environment	Temperature : 0℃ to 40℃(32℉ to 104℉)/Humidity: 20-80% (non-condensation)
Power Off Condition	Approx.0.3W
Bezel Width	T/R/L: 9.5 mm (0.38") B: 15.5 mm (0.61")
Dimensions (W x H x D)	1098 x 634 x 46 mm (43.2" x 24.9" x 1.8")
Standby Condition	Approx.0.5W
Wall-hanging pitch	VESA Compliant 400 x 400 mm(15.8" x 15.8")
Screen size	49-inch (1232 mm)
Panel Surface Treatment	Anti-Glare
Haze	1%



ایران پاناسونیک

آدرس سایت  :         www.iranpanasonic.ir

تلفن :        [phone]

مانیتور صنعتی پاناسونیک مدل TH-55SF2U

Brightness

	450 cd/m2
Contrast Ratio	1100:1
Aspect Ratio	16:9
Response Time	12 ms (G to G)
Effective Display Area (W x H)	1209 x 680 mm (47.6" x 26.7")
Number of Pixels (H x V)	1920 x 1080 pixels
Panel Type	LCD IPS Panel/E-LED
Viewing Angle (Horizontal/Vertical)	178°/178°(CR≧10)
Dynamic Contrast	50000:1
Weight	Approx. 18.0 kg(39.7 lbs.)
Power consumption	115W
Power Requirements	110-127/220-240 V AC,50/60 Hz
Operating environment	Temperature : 0℃ to 40℃(32℉ to 104℉)/Humidity: 20-80% (non-condensation)
Power Off Condition	Approx.0.3W
Bezel Width	T/R/L: 9.5 mm (0.38") B: 15.6 mm (0.62")
Dimensions (W x H x D)	1234 x 710 x 46 mm (48.5" x 28.0" x 1.8")
Standby Condition	Approx.0.5W
Wall-hanging pitch	VESA Compliant 400 x 400 mm(15.8" x 15.8")
Screen size	55-inch (1387 mm)
Panel Surface Treatment	Anti-Glare
Haze	1%







ایران پاناسونیک

آدرس سایت  :         www.iranpanasonic.ir

تلفن :        [phone]

مانیتور صنعتی پاناسونیک مدل TH-65SF2U

Brightness

	450 cd/m2
Contrast Ratio	1300:1
Aspect Ratio	16:9
Response Time	10 ms (G to G)
Effective Display Area (W x H)	1428 x 803 mm (52.6" x 31.6")
Number of Pixels (H x V)	1920 x 1080 pixels
Panel Type	LCD IPS Panel/E-LED
Viewing Angle (Horizontal/Vertical)	178°/178°(CR≧10)
Dynamic Contrast	50,000:1
Weight	Approx. 29.8 kg(65.7 lbs.)
Power consumption	155W
Power Requirements	110-127/220-240 V AC,50/60 Hz
Operating environment	Temperature : 0℃ to 40℃(32℉ to 104℉)/Humidity: 20-80% (non-condensation)
Power Off Condition	Approx.0.3W
Bezel Width	T/R/L: 9.5 mm (0.38") B: 15.7 mm (0.62")
Dimensions (W x H x D)	1452 x 834 x 64 mm (57.2" x 32.9" x 2.5")
Standby Condition	Approx.0.5W
Wall-hanging pitch	VESA Compliant 400 x 400 mm(15.8" x 15.8")
Panel Surface Treatment	Anti-Glare
Haze	1%
Screen size	65-inch (1639 mm)







ایران پاناسونیک

آدرس سایت  :         www.iranpanasonic.ir

تلفن :        [phone]

مانیتور صنعتی پاناسونیک مدلTH-32EF1U









Specification	Description
Weight	approx.5.3 kg
Dimensions (W x H x D)	727 x 426 x 64 mm
Screen size	32-inch(801 mm)
Brightness	350 cd/m2
Contrast Ratio	1400:1
Aspect Ratio	16:9
Response Time	8.0 ms (G to G)
Power consumption	65 W
Power Requirements	110-127V/220-240V 50Hz / 60Hz
Effective Display Area (W x H)	698 x 392 mm
Number of Pixels (H x V)	1920 x 1080
Panel Type	LCD IPS Panel / D-LED
Viewing Angle (Horizontal/Vertical)	178°/ 178°(CR≧10)
Panel Surface Treatment	Anti-Glare
Haze	1%

ایران پاناسونیک

آدرس سایت  :         www.iranpanasonic.ir

تلفن :        [phone]

مانیتور صنعتی پاناسونیک مدل TH-75BQE1W

Specification	Description
Weight	66 Kg / 145.5 lbs.
Screen size	75-inch (1893 mm / 74.5 inch)
Brightness	400cd/m2
Contrast Ratio	4000 : 1
Aspect Ratio	16:9
Response Time	8 ms(G to G)
Power consumption	370 W
Power Requirements	100V AC 50/60 Hz,200-240V AC 50/60Hz
Viewing angle	178°/178°(CR≧10)
Effective Display Area (W x H)	1650.2 x 928.2 ｍm
Number of Pixels (H x V)	3840 x 2160
Power Off Condition	Approx. 0W
Panel Type	VA/Direct LED
Standby Condition	Approx. 0.5W
Dimensions (W x H x D)	1710 x 1072 x 102 ｍｍ / 67.3" x 42.2" x 4.0" (Mounted the speaker in the case of lateral placement)
Panel Surface Treatment	Anti-Glare
Haze	N/A





ایران پاناسونیک

آدرس سایت  :         www.iranpanasonic.ir

تلفن :        [phone]
